For economical signage in 24/7 commercial environments, the 32” MultiSync® M321 delivers all the professional performance and features you need, whilst minimising the cost of ownership. With a 450 cd/m2 brightness output and anti-glare panel, the viewer enjoys excellent visual quality unhindered by reflections, with a slim, aesthetic design for unobtrusive integration.
Featuring multiple industry standard digital and analogue signal inputs, the M321 is future-proof for flexible integration. It also features full external control support through both RS-232 or LAN connectivity enabling operators to achieve time and cost savings when managing an estate of displays.
The full metal chassis, high end componentry and integrated schedule function affords peace of mind for extended runtimes, ideal for retail and transportation applications.
| Product Information | |
|---|---|
| Product Name | NEC MultiSync® M321 |
| Product Group | LCD 32″ Message Large Format Display |
| Display | |
| Panel Technology | IPS with Direct LED backlights |
| Screen Size [inch/cm] | 32 / 80 |
| Aspect Ratio | 16:9 |
| Brightness [cd/m²] | 450 |
| Contrast Ratio (typ.) | 1100:1 |
| Viewing Angle [°] | 178 horizontal / 178 vertical (at contrast ratio 10:1) |
| Colour Depth [bn] | 16.7 (8bit) |
| Response Time (typ.) [ms] | 8 |
| Panel Refresh Rate [Hz] | 60 |
| Haze Level [%] | Pro (28) |
| Supported Orientation | Face Up ±; Landscape; Portrait |
| Resolution | |
| Native Resolution | 1920 x 1080 |
| Supported Resolutions | 1280 x 720; 1366 x 768; 1500 x 1050; 2560 x 1440; 1280 x 1024; 1400 x 1050; 1920 x 1080; 2560 x 1600; 1360 x 768; 1600 x 1200; 2048 x 1536; 4096 x 2160 |
| Synchronization Rate | |
| Horizontal Frequency [kHz] | 26 – 91.1 |
| Vertical Frequency [Hz] | 23 – 86 |
| Connectivity | |
| Input Video Analogue | 1 x VGA |
| Input Video Digital | 1 x DisplayPort (with HDCP); 2 x HDMI (with HDCP) |
| Output Video Digital | 1 x DisplayPort; 2 x HDMI |
| Input Audio Analogue | 1 x 3.5 mm jack |
| Input Audio Digital | 1 x LAN 100Mbit; remote control wire (3.5mm jack); RS232 |
| Output Audio Analogue | 1 x 3.5 mm jack |
| Input Detect | Custom; first / second |
| Sensors | |
| Temperature Sensor | Integrated, 3 sensors, triggered actions programmable |
| Electrical | |
| Power Consumption [W] | 40 shipping |
| Power Savings Mode [W] | < 0.5; < 2 (Networked Standby) |
| Power Management | VESA DPMS |
| Power Supply | 100-240 V AC; 50/60 Hz; internal |
| Environmental Conditions | |
| Operating Temperature [°C] | +0 to +40 |
| Operating Humidity [%] | 20 to 80 |
| Storage Humidity [%] | 10 to 90 |
| Storage Temperature [°C] | -20 to 60 |
| Mechanical | |
| Dimensions (W x H x D) [mm] | 726.5 x 425.4 x 66.5 |
| Weight [kg] | 6.3 |
| Bezel Width [mm] | 10.1 (top); 11.1 (left and right); 17.2 (bottom) |
| VESA Mounting [mm] | 100 x 100 (FDMI); 200 x 200 (FDMI); 4 holes; M4 |
| Ingress Protection | IP5x (front); IP2x (back) |
| Packaging Dimensions (W x H x D) [mm] | 870 x 527 x 160 |
| Packaging Weight [kg] | 9.8 |
| Colour Bezel | Pantone 426M (black) |
| Material | Metal |
| MediaPlayer | |
| Supported File Storage / File System | USB 2.0 / FAT16, FAT32 |
| Supported Image Formats | JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640 |
| Supported Video Formats | |
| Supported Video Formats | MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160p@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160p@60Hz); audio: LPCM, MP3, AAC; WMV (video H.264, Windows Media Video 9, max res 1080p@30Hz, audio WMA 9, WMA 10 Pro) |
| Supported Audio Formats | MP3 (MP3); max. bit-rate 320 kbit/s |
| Available Options | |
| Accessories | Feet (ST-32M); Presence Sensor (KT-RC3); Wall mount (PDW T XS) |
| External Computing | MPi4 Box; OPS/SDM standalone adapter to integrate any OPS/SDM computing or interface module |
| Regulatory | |
| Safety and Ergonomics | CE; EAC; RoHS |
| Pixel Failure Class | ISO 9241-307, Class 2 |
| Fire Protection | Metal backcover, plastic material certified acc. to UL94-5VB |
| Green Features | |
| Energy Efficiency | Energy consumption: 41 kWh/1000 h; Energy efficiency class: G; LED backlight |
| Ecological Standards | EnergyStar 8.0 |
| 3rd Party Certifications | |
| Crestron | Certified for Crestron Connected |
| Additional Features | |
| Special Characteristics | DICOM Simulation; HDMI ARC; Powered USB Port (10 W); Removable Logo |
| Shipping Content | 2x AAA batteries; Display; HDMI Cable; Power Cable; Remote Control |
| Operating Hours | 24/7 |
| External Control | AMX NetLinx Support; ASCII Control Commands; Crestron Connected; HTTP Browser; PJLink; Scheduled Timer; SNMP |
| Remote Management | Automated Monitor Alert; NEC NaViSet Administrator 2 |
| Safety | Disable HW Buttons; Disable IR Functionality; Emergency Notification |
