| Product Information |
| Product Name |
NEC P627UL |
| Product Group |
Professional LCD Laser Projector |
| Image |
| Projection Technology |
3LCD Technology |
| Native Resolution |
1920 x 1200
(WUXGA) |
| Aspect Ratio |
16:10 |
| Contrast Ratio |
3000000:1 |
| Brightness |
6200 Lumen (approx. 60% in Eco Mode); compliant with ISO21118-2020 |
| Lamp |
Laser Light Source |
| Light Source Life [hrs] |
20000 1 |
| Lens |
F= 1.5–2.1, f= 17.2–27.7 mm |
| Lens shift |
H:±29, V:+60,-0 |
| Keystone correction |
+/- 30° manual horizontal / +/- 30° manual vertical |
| Projection Factor |
1.23 – 2 : 1 |
| Projection Distance [m] |
0.8 – 12.9 |
Screen Size (diagonal)
[cm] / [inch] |
Maximum: 762 / 300″; Minimum: 76.2 / 30″ |
| Zoom |
Manual; x1.6 |
| Focus Adjustment |
Manual |
| Supported Resolutions |
1920×1200 (Maximum resolution of analog input);
3840 x 2160 (Maximum resolution of digital input);
3840×2160 @ 30hz digital |
| Connectivity |
| RGB (analog) |
Input: 1 x Mini D-sub 15 pin |
| Digital |
Input: 1 x HDBaseT; 2 x HDMI™ supporting HDCP |
| Audio |
Input: 1 x 3.5 mm Stereo Mini Jack for Computer analog; 2 x HDMI audio
Output: 1 x 3.5 mm Stereo Mini Jack (variable) |
| Control |
Input: 1 x D-Sub 9 pin (RS-232) (male) |
| LAN |
1 x RJ45; Optional WLAN |
| USB |
1 x Type B (for Service); 1x Type A (USB 2.0 high speed) with 2.0A Power
Supply; 1x Type A (W-LAN Dongle) |
| Video Signals |
NTSC 3.58; NTSC 4.43; PAL; PAL-M; PAL-N; PAL60; SECAM |
| Remote Control |
| Remote Control |
Aspect Ratio; Audio Control; Auto Adjust; Eco Mode Control; Freezefunction;
Help-function; ID set; Keystone Correction; Magnify-function;
Page (up, down); Picture Adjust; Picture Mute; Power (On-OFF); Select (up,
down, left, right); Source Select |
| Electrical |
| Power Supply |
100-240 V AC; 50 – 60 Hz |
| Power Consumption [W] |
318 (Normal) / 237 (Eco) / 1.6 (Network Stand-by) / 0.3 (Stand-by) |
| Mechanical |
| Dimensions (W x H x D)[mm] |
480 x 122 x 407 (without lens and feet) |
| Weight [kg] |
9.7 |
| Fan Noise [dB (A)] |
22 / 27 (Eco / Normal) |
| Colour Versions |
White |
| Environmental Conditions |
| Operating Temperature[°C] |
5 to 40 |
| Operating Humidity [%] |
20 to 80 |
| Storage Temperature[°C] |
-10 to 50 |
| Storage Humidity [%] |
20 to 80 |
| Ergonomics |
| Safety and Ergonomics |
CE; EAC; ErP; RoHS; TUEV Type Approved |
| Speakers [W] |
1 x 20 (mono) |
| Additional Features |
| Special Characteristics |
Auto Power ON/OFF; Carbon Savings Meter; Constant Brightness Mode;
Control ID Function; DICOM simulation; Direct Power-Off Function; Free
Tilt; HDBaseT; Help Function; HTTP Browser Control; Kensington security
slot; Keypad Lock; Light Source Adjustment; Magnify; MultiPresenter
Function; NaViSet Administrator 2; Optional User Logo; OSD with 30
languages; Password Security System; Plug&Play W-LAN Option; Portrait
Setting; Quick Start; Source Select with Beep Function; Test Pattern;
Unique Power Saving Functions; USB Viewer; Virtual Remote for direct PC
control |
| Green Features |
| Ecological Materials |
Downloadable manuals; ECO packaging |
| Ecological Standards |
ErP compliant; RoHs compliant |
| Shipping Content |
| Shipping Contents |
2x AAA Batteries; IR Remote Control (477E); Lens Cap; Power Cord (1.8
m); Projector; Quick Setup Guide; Security Sticker; Users Manual; Utility
software |
| Optional Accessories |
| Optional Accessories |
Universal Ceiling Mounts (PJ01UCM, PJ02UCMPF); Wireless LAN module
(NP05LM2; NP05LM4; NP05LM5) |
