Enhance Your Office Efficiency with the Compact, Smart Color MFP
The SHARP BP-22C Series Color Multifunction Printer combines a compact footprint, sleek design, and advanced functionality to meet the needs of today’s dynamic workplaces. Its 7-inch intuitive touch panel offers effortless access to essential features, while tools like Rotate Sort and Duplex printing organize multi-page outputs efficiently, segregating sets horizontally and vertically.
With seamless mobile connectivity and optional wireless functionality, the BP-22C Series is perfect for SMEs, co-working spaces, front desks, government offices, hospitals, financial agencies, and reception areas. Delivering stable image quality, robust security, and eco-friendly performance, it empowers users to create professional, on-demand color prints with ease, delivering an exceptional user experience.
Choose the SHARP BP-22C Series for secure, sustainable, and high-performance document solutions designed to grow with your business.
| Type | Desktop |
| Engine speed (colour & B/W) | A4 (8 1/2″” x 11″”): Max. 25 ppm A3 (11″” x 17″”): Max. 14 ppm |
| Control panel display | 7.0-inch colour LCD touchscreen |
| Paper Size | Max. A3W (12″ x 18″), min. A6 (5 1/2″ x 8 1/2″) |
| Paper capacity(80 g/m²) | Standard: 350 sheets (250-sheet tray and 100-sheet multi bypass tray) Maximum: 1,850 sheets (350 sheets & optional 3 × 500-sheet tray) |
| Paper weight | Tray 1: 60 g/m2 to 105 g/m2 (16 lbs bond to 28 lbs bond) Trays 2–4 (BP-CS14/DE16): 60 g/m2 to 220 g/m2 (16 lbs bond to 80 lbs cover) |
| Warm-up time | 27 sec. |
| Memory | 2 GB (copy/print shared) 16 GB eMMC |
| Power requeirements | Rated local AC voltage ±10%, 50/60 Hz |
| Power Consumption | Max. 1.84 kW (220 V to 240 V) |
| Dimensions(W×D×H) including document cover | 560 x 581 x 653 mm (22 1/16″ x 22 7/8″ x 25 23/32″) |
| Weight(approx.) | 52 kg (114.7 lbs) |
| Original size | Max. A3 (11″ x 17″) |
| First copy time | Colour: 11.5 sec. B/W: 8.0 sec. |
| Resolution | Scan: 600 x 600 dpi, 600 x 400 dpi Print: 600 x 600 dpi Equivalent to 256 levels |
| Continuous copy | Max. 999 copies |
| Gradation | Equivalent to 256 levels |
| Zoom range | 25% to 400% (25% to 200% using RSPF) in 1% increments |
| Preset copy rations | Metric: 10 ratios (5R/5E), inch: 8 ratios (4R/4E) |
| Resolution | 600 x 600 dpi |
| Interface | Standard: USB 2.0 (host, high-speed), 10Base-T/100Base-TX/1000Base-T Option: wireless LAN (IEEE 802.11 b/g/n) |
| Network protocols | TCP/IP |
| Printing protocols | LPR, Raw TCP (port 9100), FTP for downloading print files,IPP, WSD |
| PDL | Standard: PCL 6 emulation Option: PostScript 3 emulation |
| Supported OS | Standard: Windows Server 2016, Windows Server 2019, Windows Server 2022, Windows 10, Windows 11, Optional: Mac OS 10.10, 10.11, 10.12, 10.13, 10.14, 10.15, 11, 12, 13, 14 |
| Available fonts | 80 fonts for PCL, 136 fonts for PostScript 3 emulation |
| Scan method | Push scan (via control panel) Pull scan (TWAIN-compliant application) |
| Scan speed | [Colour & B/W] Max. 31 originals/min. |
| Resolution | Push scan: 100, 150, 200, 300, 400, 600 dpi Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi 50 dpi to 9,600 dpi via user setting |
| File formats | TIFF, PDF, JPEG |
| Scan destinations | FTP server/network folder (SMB)/USB drive Option:desktop (Requires Network Scanner Tool Lite) |
| Document filing capacity | – |
| Stored jobs | – |
| Storage folders | – |
| Compression method | – |
| Communication protocol | – |
| Transmission time | – |
| Modem speed | – |
| Transmission resolution | – |
| Recording size | – |
| Memory | – |
| Grey scale levels | – |
